How to Laser Engrave Wood: 6 Tips for Better Results
Laser engraving wood is one of the most popular applications of CO2 laser engraving machines. With the right settings and techniques, laser engraving can create detailed patterns, personalized gifts, signs and wooden crafts with high precision.
However, achieving clean and professional engraving results requires proper material selection, focus adjustment and laser parameter settings. In this article, we share 6 practical tips for laser engraving wood to help improve engraving quality and reduce common problems such as smoke marks and uneven engraving.
- Low-tack masking tape
Before engraving wood, cover the surface of the wood with low-tack masking tape. In this case, the surface of the wood won’t be dotted with brown or gray stains caused by smoke. Once the job is finished, take out the tape and you will find it’s cleaner than usual. This method can be time consuming if you are processing some very detailed projects. Then a paint scraper can be utilized to speed things up.
- Denatured alcohol
After engraving work, prepare a bottle of denatured alcohol and a white piece of cloth to clean burn marks. Here 2 things should be heeded – you must spray the alcohol evenly to protect engraving results and you should use an uncolored piece of cloth (like white one) to wipe the burn marks without being stained by the dye. - Burn at 1200 DPI
A higher engraving resolution can be achieved by increasing more dots per inch (DPI). More DPI usually means more times the laser will fire. Therefore the wood can be burned darker and accordingly twice time may be taken to engrave if adopting this method. So you should make a balance between engraving resolution and time spending.
- Back out your focus .2″
Do not set the focus of your laser automatically and set it as manually instead. You can use a digital caliper and drop your laser bed .2″, which can produce less mess and smoke. In this way, not only the engraved wood surface is more cleaner than ever before, but also you will spend less time cleaning the wood surface. This method is particularly recommended when engraving pretty detailed projects. - Use real hardwood for large engraving
Our past engraving experiences told us that plywood does not work well as we had imagined. Then we chose hard wood for large engraving for 3 reasons. Firstly, the grain on the wood surface runs in a consistent direction, beautiful and brilliant. The second is that hardwood is heavier than plywood and a higher engraving quality can be ensured. And the last one is that the hardwood surface can be totally controlled.
- Do some experiments on wood engraving
Although we didn’t process plywood well compared to hardwood, we do think that you are likely to engrave plywood perfectly with skilled craftsmanship and advanced engravers. It’s recommended to do more engraving experiments on different kinds of wood, from which you may figure out better laser solutions.
Laser engraving wood is a common technology in laser engraving industry, but further exploring the huge value in wood is the permanent mission of laser engraving technologies and machines. Thus we still have a long way to go to enhance laser technologies and craftsmanship.
If you are looking for a reliable CO2 laser engraving machine for wood, acrylic and other non-metal materials, Reaying provides professional laser engraving and cutting solutions.
FAQ
What wood is best for laser engraving?
Hardwood, plywood and MDF are commonly used materials for laser engraving. Different wood types require different laser settings.
What laser machine is suitable for wood engraving?
CO2 laser engraving machines are widely used for wood engraving because they provide precise cutting and engraving performance on non-metal materials.
How can I avoid burn marks when engraving wood?
Using masking tape, adjusting focus and optimizing laser power settings can help reduce burn marks.
