Metal Sheet And Square Tube/ Round Pipe Fiber Laser Cutting Machine
Model:
RY-F1325T
Function:
Cutting
Input Voltage:
Custom Made
Laser Power:
500W-25000W
Laser Source:
Genuines Raycus
Working Area:
1300*2500mm
Laser Source
The best performed and the most famous laser source in China. The laser source lifetime is more than 100,000 hours and almost free maintenance for life.
Laser Head
Famous laser head for metal cutting. Easy to operate and with nice working performance.
Control System
Domestic famous control system for metal cutting.Working stability, widely used and ease operate.
Servo Driver and Motors
Famous servo driver and motors in the world, and widely used in the industry machine. With its stability and working accuracy.
Sawtooth Worktable
Equipped with sawtooth worktable, to put and down heavy metal easier, and to keep materials and products clean enough.
Double driver Rail Guide and Gear
With double drive square rail guide and gears, to keep the machine working stability and accuracy.
DSP controller
DSP controller is clear and easy to operate, even there is some distance from the fiber cutting machine.
Machine Lathe
The lathe is founded by high-quality steel that ensures the high stability ,all the three axises are using imported straight-quadrate rails.
Technical Parameters
| Model | RY-F1325T |
|---|---|
| Laser Power | 500W-25000W |
| Working Area | 1300*2500 mm |
| Laser Type | Raycus (IPG / Nlight) Fiber laser source is optional |
| Laser Wavelength | 1064nm |
| Positioning Accuracy | ≤ ±0.025mm/m |
| Re-positioning Accuracy | ≤±0.02mm/m |
| Graphic Format Supported | BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. |
| Warranty | 5 YEARS |
Applications & Suitable Materials
This metal sheet and square tube round pipe fiber laser cutting machine is widely used for stainless steel, carbon steel, aluminum alloy and other metal sheets, as well as square pipe, round pipe and rectangular pipe cutting. Suitable for metal fabrication, construction engineering and furniture manufacturing industries.
FAQ
What is RY-F1325T used for?
It is a dual-purpose machine for metal sheet, square pipe and round pipe cutting.
What laser power options are available?
500W to 25000W optional to fit different cutting thickness.
Can it cut both sheet and pipe?
Yes, one machine completes sheet and pipe cutting to save cost.
Is the cutting quality good?
Smooth cutting edge, no burr, no need for secondary processing.
What is the warranty period?
5 years full machine warranty for stable after-sales support.
