Fiber Laser Cutting Machine RY-L1530T For Metal Sheet And Metal Pipes Processing
Multi-purpose Metal sheet and pipes fiber laser cutter is designed for cutting not only metal sheets and metal plates with different thickness, but also metal pipes and metal tubes to defferent shapes.
Model:
RY-L1530T
Function:
Cutting
Input Voltage:
Custom Made
Laser Power:
500W-25000W
Laser Source:
Genuines Raycus
Working Area:
1300*2500mm
Laser Source
The best performed and the most famous laser source in China. The laser source lifetime is more than 100,000 hours and almost free maintenance for life.
Laser Head
Famous laser head for metal cutting. Easy to operate and with nice working performance.
Control System
Domestic famous control system for metal cutting.Working stability, widely used and ease operate.
Servo Driver and Motors
Famous servo driver and motors in the world, and widely used in the industry machine. With its stability and working accuracy.
Sawtooth Worktable
Equipped with sawtooth worktable, to put and down heavy metal easier, and to keep materials and products clean enough.
Double driver Rail Guide and Gear
With double drive square rail guide and gears, to keep the machine working stability and accuracy.
DSP controller
DSP controller is clear and easy to operate, even there is some distance from the fiber cutting machine.
Machine Lathe
The lathe is founded by high-quality steel that ensures the high stability ,all the three axises are using imported straight-quadrate rails.
Technical Parameters
| Model | RY-L1530T |
|---|---|
| Laser Power | 500W-25000W |
| Working Area | 1500*3000 mm |
| Laser Type | Raycus (IPG / Nlight) Fiber laser source is optional |
| Laser Wavelength | 1064nm |
| Positioning Accuracy | ≤ ±0.025mm/m |
| Re-positioning Accuracy | ≤±0.02mm/m |
| Graphic Format Supported | BMP, JPG, GIF, TGA, Ai, DXF, PLT, PNG, TIF, ai, DXF, DST, etc. |
| Warranty | 5 YEARS |
